Aerfoam 180 Bend 45°

Name: Aerfoam 180 Bend 45°
Brand: Ubbink
SKU: UBBINK-188282
Price: 35.00 AUD
Availability: OutOfStock

Sold out

Thanks for contacting us. We'll get back to you as soon as possible.

The Aerfoam 180 mm 45° Bend allows smooth directional changes within the Aerfoam system. Made from lightweight, insulated EPE foam, it helps prevent condensation, reduce heat loss, and absorb sound. The bend connects easily to other Aerfoam parts using dedicated connectors and can be securely mounted to walls or ceilings with brackets. Ideal for both central mechanical ventilation and heat pump systems.

Insulated to prevent condensation and minimise heat loss
Sound-absorbing material for a better indoor comfort
Easy mechanical connection and secure mounting
Lightweight and easy to cut, ensuring quick, effortless installation
Impact resistant
Airtight mechanical connections
Airtightness class D/ATC 2 up +/- 200 Pa, which minimises fan energy use and sound production
EPD certified and REACH compliant

Specifications

General

Product Name	Aerfoam 180 Bend 45°
Type	Bends
GTIN	8713645123097
Trade Name	Aerfoam

Technical

Colour	Grey
Material	EPE
Airflow Direction	Supply / Extract
Internal Duct Dimension	180 mm
Insulation Thickness	16 mm

Dimensions

Length Gross	258 mm
Width	212 mm
Height	261 mm
Net Weight	0.06 kg

Logistical

Intrastat	39259080
Number per Packaging	1
Base Unit Packaging	Unpacked
Gross Weight	0.06 kg
Packaging / Trade Length	258 mm
Packaging / Trade Width	212 mm
Packaging / Trade Height	261 mm

Performance

CE String	-
Temperature Resistance (min.)	-30 °C
Temperature Resistance (max.)	60 °C
Installation Temperature (min.)	0 °C
Installation Temperature (max.)	50 °C
